Our Products

Our organization is a well known dealer of H. R. Pipes, C. R. Tubes, and C. R. C. A. Strips, Scaffolding and Swaged Poles (Electrical). Apart from this, we are also dealing with angles, flats, channels, and rods. We have been able to satisfy our huge client base by providing them superior quality products. Our range is appreciated for its durability, reliability, and other striking features. These are available in various standards like IS, ASTM/ANSI, BS, JIS, and DIN. Our range encompasses the following:

Metal Pipes

Our organization is engaged in dealing a wide range of H. R. Pipes, C. R. Tubes, C. R. C. A. Strips, Scaffolding and Swaged Poles (Electrical). Other than this, we also deal with angles, flats, channels and rods. These are widely admired for its durability, high strength and corrosion resistance.

  • Cold Rolled Tubes (CR)
  • C. R. C. A. Strips
  • Mild Steel Joist
  • Mild Steel Angles
  • Mild Steel Channels
  • Mild Steel Flats
  • Mild Steel Plates
  • MS Pipes

Industrial Pipes

Our client can avail from us wide range of Pipes basically of steel which we procure from our reputed vendors who manufacture these with quality material. Moreover, we are able to supply our pipes in bulk quantities as the specific requirement of our clients.

  • Mild Steel Pipes
  • GI Pipes
  • CR Tubes
  • Swaged Poles (Electrical)
  • Electric Resistance Welded (ERW) Pipes
  • Galvanized Pipes (GI)
  • Scaffolding
  • Rectangular Hollow Sections Pipes (RHS)

Mild Steel Products

Our client can avail from us wide range of Mild Steel Products which is made from high-grade mild steel and is well known for their strength and durability. The mild steel products are used in a variety of construction and other fabrication applications.

  • Square Hollow Pipes
  • TMT Bars
Cold Rolled Tubes (CR)

CR Tubes is manufacture from cold rolled strips in various thickness from 0.50mm - 3.00mm and normal sign show in our specification cr tubes is used in furniture manufacturer bicycle industries, auto industries etc...











PRODUCT RANGE OF PRECISION TUBES
SIZE Thickness
O.D. 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.40 1.50 1.60 1.80 2.00 2.20 2.50 2.80 3.00 3.20
INCH MM
1/2 " 12.70 0.179 0.207 0.235 0.262 0.289 0.315 0.340 0.390 0.414 0.438 0.484 0.527
15.00 0.213 0.247 0.280 0.313 0.345 0.377 0.408 0.470 0.499 0.529 0.585 0.641
5/8 " 15.88 0.226 0.262 0.298 0.332 0.367 0.401 0.434 0.500 0.532 0.563 0.625 0.685
18.00 0.257 0.298 0.339 0.379 0.419 0.458 0.497 0.572 0.610 0.647 0.719 0.789
18.20 0.260 0.302 0.343 0.384 0.424 0.464 0.503 0.580 0.618 0.655 0.728 0.799
3/4 " 19.05 0.273 0.317 0.360 0.403 0.445 0.487 0.528 0.609 0.649 0.689 0.766 0.841
21.30 0.302 0.350 0.399 0.446 0.493 0.540 0.586 0.677 0.721 0.765 0.852 0.937 1.035
7/8 " 22.23 0.320 0.372 0.423 0.473 0.524 0.573 0.622 0.719 0.767 0.814 0.907 0.998 1.087 1.216
24.80 0.354 0.411 0.468 0.524 0.580 0.635 0.690 0.798 0.851 0.904 1.008 1.110
1 " 25.40 0.367 0.426 0.485 0.544 0.602 0.659 0.716 0.829 0.884 0.939 1.048 1.154 1.259 1.412
26.80 0.388 0.451 0.513 0.575 0.636 0.697 0.758 0.877 0.936 0.994 1.110 1.223
27.40 0.397 0.461 0.525 0.588 0.651 0.713 0.775 0.898 0.958 1.018 1.136 1.253
11/8 " 28.58 0.414 0.481 0.548 0.614 0.680 0.745 0.810 0.938 1.002 1.065 1.189 1.311 1.431 1.608
30.20 0.438 0.509 0.580 0.650 0.720 0.789 0.858 0.994 1.062 1.129 1.261 1.391 1.519 1.708
11/4 " 31.75 0.461 0.536 0.611 0.685 0.758 0.831 0.904 1.048 1.119 1.190 1.330 1.467 1.603 1.803
33.30 0.484 0.563 0.641 0.719 0.797 0.874 0.950 1.101 1.176 1.251 1.398 1.544 1.686 1.898
34.93 0.508 0.591 0.673 0.755 0.837 0.918 0.998 1.158 1.237 1.315 1.471 1.624 1.776 1.999
11/2 " 38.10 0.555 0.646 0.736 0.826 0.915 1.004 1.092 1.267 1.354 1.440 1.611 1.781 1.948 2.195 2.438 2.597
40.00 0.678 0.773 0.868 0.962 1.055 1.148 1.333 1.424 1.515 1.696 1.874 2.051 2.312 2.569 2.737
17/8 " 41.28 0.701 0.799 0.896 0.993 1.090 1.186 1.377 1.472 1.566 1.753 1.937 2.120 2.391 2.657 2.832
42.70 0.725 0.827 0.928 1.028 1.129 1.228 1.426 1.524 1.622 1.816 2.007 2.197 2.478 2.755 2.937
13/4 " 44.45 0.755 0.861 0.967 1.072 1.176 1.280 1.486 1.589 1.691 1.893 2.094 2.292 2.586 2.876 3.067
48.60 0.826 0.943 1.059 1.174 1.289 1.403 1.630 1.742 1.855 2.077 2.298 2.517 2.842 3.163 3.374
2 " 50.80 1.228 1.348 1.468 1.706 1.824 1.941 2.175 2.407 2.637 2.978 3.315 3.536
21/4 " 57.15 1.384 1.520 1.656 1.925 2.059 2.192 2.457 2.720 2.981 3.369 3.753 4.006 4.258
60.30 1.462 1.605 1.749 2.034 2.175 2.316 2.597 2.876 3.152 3.564 3.971 4.239 4.506
21/2 " 63.50 1.540 1.692 1.844 2.144 2.294 2.442 2.739 3.033 3.326 3.761 4.191 4.476 4.759
3 " 76.20 2.220 2.583 2.763 2.944 3.303 3.660 4.015 4.544 5.068 5.416 5.761
81.20 2.755 2.948 3.141 3.525 3.906 4.286 4.852 5.414 5.786 6.156
88.90 3.231 3.443 3.864 4.284 4.701 5.324 5.942 6.352 6.760
114.00 4.160 4.433 4.978 5.522 6.063 6.871 7.675 8.208 8.740
121.50 4.437 4.729 5.311 5.891 6.470 7.333 8.193 8.763 9.331
MS Pipes

We offer all variety of MS pipes as per IS: 1239/1161/9295 (black pipes), which are extensively used in construction, general engineering, industrial and automobile manufacturing purposes. Our pipes are widely appreciated for their construction, durability and corrosion resistance. Our product range varies from 15NB to 400NB and physical properties ranging from Yst 210-310. We also offers customized ms pipes of various sizes cut to length to suit specific requirements of our clients.







Nominal Bore
& Series
Outside Diameter (OD) Wall Thickness (T) Nominal mass of steel tube Sockets
Max Min Plain End Screwed & Socketed Min OD Min Length
mm inch mm mm mm swg kg/mtr mrs/mt kg/mtr mtrs/mt mm mm
15L 0.50 21.4 21.0 2.0 14 0.947 1056 0.956 1046 27.0 37.0
15M 0.50 21.8 21.0 2.6 12 1.21 826 1.22 820 27.0 37.0
15H 0.50 21.8 21.0 3.2 10 1.44 694 1.45 690 27.0 37.0
20L 0.75 26.9 26.4 2.3 13 1.38 725 1.39 719 32.5 39.0
20M 0.75 27.3 26.5 2.6 12 1.56 641 1.57 637 32.5 39.0
20H 0.75 27.3 26.5 3.2 10 1.87 535 1.88 532 32.5 39.0
25L 1.00 33.8 33.2 2.6 12 1.98 505 2.00 500 39.5 46.0
25M 1.00 34.2 33.3 3.2 10 2.41 415 2.43 412 39.5 46.0
25H 1.00 34.2 33.3 4.0 8 2.93 341 2.95 339 39.5 46.0
32L 1.25 42.5 41.9 2.6 12 2.54 394 2.57 389 49.0 51.0
32M 1.25 42.9 42.0 3.2 10 3.10 323 3.13 319 49.0 51.0
32H 1.25 42.5 41.9 4.0 8 3.79 264 3.82 262 49.0 51.0
40L 1.50 48.4 47.8 2.9 11 3.23 310 3.27 306 56.0 51.0
40M 1.50 48.8 47.9 3.2 10 3.56 281 3.60 278 56.0 51.0
40H 1.50 48.8 47.9 4.0 8 4.37 229 4.41 227 56.0 51.0
50L 2.00 60.2 59.6 2.9 11 4.08 245 4.15 241 68.0 60.0
50M 2.00 60.8 59.7 3.6 9 5.03 199 5.10 196 68.0 60.0
50H 2.00 60.8 59.7 4.5 7 6.19 162 6.26 160 68.0 60.0
65L 2.50 76.0 75.2 3.2 10 5.71 175 5.83 172 84.0 69.0
65M 2.50 76.6 75.3 3.6 9 6.42 156 6.54 153 84.0 69.0
65H 2.50 76.6 75.3 4.5 7 7.93 126 8.05 124 84.0 69.0
80L 3.00 88.7 87.9 3.2 10 6.72 149 6.89 145 98.0 75.0
80M 3.00 89.5 88.0 4.0 8 8.36 120 8.53 117 98.0 75.0
80H 3.00 89.5 88.0 4.8 6 9.90 101 10.10 99 98.0 75.0
100L 4.00 113.9 113.0 3.6 9 9.75 103 10.00 100 124.0 87.0
100M 4.00 115.0 113.1 4.5 7 12.20 82 12.50 80 124.0 87.0
100H 4.00 115.0 113.1 5.4 5 14.50 69 14.80 68 124.0 87.0
125M 5.00 140.8 138.5 4.8 6 15.90 63 16.40 61 151.0 96.0
125H 5.00 140.8 138.5 5.4 5 17.90 56 18.40 54 151.0 96.0
150M 6.00 166.5 163.9 4.8 6 18.90 53 19.5 51 178.0 96.0
150H 6.00 166.5 163.9 5.4 5 21.30 47 21.90 46 178.0 96.0
GI Pipes

These are pipes are suitable for irrigation and water supply, plumbing, cold storage applications, scaffolding, antenna and telecom towers, water wells etc.











Nominal Bore
& Series
Outside Diameter (OD) Wall Thickness (T) Nominal mass of steel tube Sockets
Max Min Plain End Screwed & Socketed Min OD Min Length
mm inch mm mm mm swg kg/mtr mrs/mt kg/mtr mtrs/mt mm mm
15L 0.50 21.4 21.0 2.0 14 0.947 1056 0.956 1046 27.0 37.0
15M 0.50 21.8 21.0 2.6 12 1.21 826 1.22 820 27.0 37.0
15H 0.50 21.8 21.0 3.2 10 1.44 694 1.45 690 27.0 37.0
20L 0.75 26.9 26.4 2.3 13 1.38 725 1.39 719 32.5 39.0
20M 0.75 27.3 26.5 2.6 12 1.56 641 1.57 637 32.5 39.0
20H 0.75 27.3 26.5 3.2 10 1.87 535 1.88 532 32.5 39.0
25L 1.00 33.8 33.2 2.6 12 1.98 505 2.00 500 39.5 46.0
25M 1.00 34.2 33.3 3.2 10 2.41 415 2.43 412 39.5 46.0
25H 1.00 34.2 33.3 4.0 8 2.93 341 2.95 339 39.5 46.0
32L 1.25 42.5 41.9 2.6 12 2.54 394 2.57 389 49.0 51.0
32M 1.25 42.9 42.0 3.2 10 3.10 323 3.13 319 49.0 51.0
32H 1.25 42.5 41.9 4.0 8 3.79 264 3.82 262 49.0 51.0
40L 1.50 48.4 47.8 2.9 11 3.23 310 3.27 306 56.0 51.0
40M 1.50 48.8 47.9 3.2 10 3.56 281 3.60 278 56.0 51.0
40H 1.50 48.8 47.9 4.0 8 4.37 229 4.41 227 56.0 51.0
50L 2.00 60.2 59.6 2.9 11 4.08 245 4.15 241 68.0 60.0
50M 2.00 60.8 59.7 3.6 9 5.03 199 5.10 196 68.0 60.0
50H 2.00 60.8 59.7 4.5 7 6.19 162 6.26 160 68.0 60.0
65L 2.50 76.0 75.2 3.2 10 5.71 175 5.83 172 84.0 69.0
65M 2.50 76.6 75.3 3.6 9 6.42 156 6.54 153 84.0 69.0
65H 2.50 76.6 75.3 4.5 7 7.93 126 8.05 124 84.0 69.0
80L 3.00 88.7 87.9 3.2 10 6.72 149 6.89 145 98.0 75.0
80M 3.00 89.5 88.0 4.0 8 8.36 120 8.53 117 98.0 75.0
80H 3.00 89.5 88.0 4.8 6 9.90 101 10.10 99 98.0 75.0
100L 4.00 113.9 113.0 3.6 9 9.75 103 10.00 100 124.0 87.0
100M 4.00 115.0 113.1 4.5 7 12.20 82 12.50 80 124.0 87.0
100H 4.00 115.0 113.1 5.4 5 14.50 69 14.80 68 124.0 87.0
125M 5.00 140.8 138.5 4.8 6 15.90 63 16.40 61 151.0 96.0
125H 5.00 140.8 138.5 5.4 5 17.90 56 18.40 54 151.0 96.0
150M 6.00 166.5 163.9 4.8 6 18.90 53 19.5 51 178.0 96.0
150H 6.00 166.5 163.9 5.4 5 21.30 47 21.90 46 178.0 96.0
SHS Pipes

Square hollow section is used for structural fabricator General engineering furniture and ship building majorly.









Hollow Section Steel Tubes
Confirming To IS 4923/1997
Dimensions and Properties of Square Hollow Section
Designation Depth or Width Thickness (T) Weight
D x B x T mm mm mm kg/m
25.0 X 25.0 X 2.6 25.00 2.6 1.69
25.0 X 25.0 X 3.2 25.00 3.2 1.98
32.0 X 32.0 X 2.6 32.00 2.6 2.26
32.0 X 32.0 X 3.2 32.00 3.2 2.69
32.0 X 32.0 X 4.0 32.00 4.0 3.19
38.0 X 38.0 X 2.6 38.00 2.6 2.75
38.0 X 38.0 X 2.9 38.00 2.9 3.03
38.0 X 38.0 X 3.2 38.00 3.2 3.29
38.0 X 38.0 X 3.6 38.00 3.6 3.63
38.0 X 38.0 X 4.0 38.00 4.0 3.95
49.5 X 49.5 X 2.9 49.50 2.9 4.07
49.5 X 49.5 X 3.6 49.50 3.6 4.93
49.5 X 49.5 X 4.5 49.50 4.5 5.95
60.0 X 60.0 X 3.2 60.00 3.2 5.50
60.0 X 60.0 X 3.6 60.00 3.6 6.11
60.0 X 60.0 X 4.5 60.00 4.5 7.43
72.0 X 72.0 X 3.2 72.00 3.2 6.71
72.0 X 72.0 X 4.0 72.00 4.0 8.22
72.0 X 72.0 X 4.8 72.00 4.8 9.66
80.0 X 80.0 X 3.2 80.00 3.2 7.51
80.0 X 80.0 X 4.0 80.00 4.0 9.22
80.0 X 80.0 X 4.8 80.00 4.8 10.87
91.5 X 91.5 X 3.6 91.50 3.6 9.67
91.5 X 91.5 X 4.5 91.50 4.5 11.88
91.5 X 91.5 X 5.4 91.50 5.4 14.01
100 X 100 X 4.0 100.00 4.0 11.74
100 X 100 X 5.0 100.00 5.0 14.41
100 X 100 X 6.0 100.00 6.0 16.98
113.5 X 113.5 X 4.5 113.50 4.5 14.99
113.5 X 113.5 X 4.8 113.50 4.8 15.92
113.5 X 113.5 X 5.4 113.50 5.4 17.74
132 X 132 X 4.8 132.00 4.8 18.71
132 X 132 X 5.4 132.00 5.4 20.88
150 X 150 X 4.0 150.00 4.0 18.01
150 X 150 X 5.0 150.00 5.0 22.26
150 X 150 X 6.0 150.00 6.0 26.40
RHS Pipes

Rectangle hollow section is used for roofing structures PEBS and major fabrications as support columns pillars.









Hollow Section Steel Tubes
Confirming To IS 4923/1997
Dimensions and Properties of Rectangular Hollow Section
Designation Depth of Section H Width of Sction B Thickness (T) Weight
D x B x T mm mm mm mm kg/m
50.0 X 25.0 X 2.9 50 25 2.9 2.98
50.0 X 25.0 X 3.2 50 25 3.2 3.24
60.0 X 40.0 X 2.6 60 40 2.6 3.73
60.0 X 40.0 X 2.9 60 40 2.9 4.12
60.0 X 40.0 X 3.6 60 40 3.6 4.98
66.0 X 33.0 X 2.6 66 33 2.6 3.69
66.0 X 33.0 X 2.9 66 33 2.9 4.07
66.0 X 33.0 X 3.6 66 33 3.6 4.93
66.0 X 33.0 X 4.5 66 33 4.5 5.95
80.0 X 40.0 X 2.9 80 40 2.9 5.03
80.0 X 40.0 X 3.2 80 40 3.2 5.50
80.0 X 40.0 X 4.0 80 40 4.0 6.71
96.0 X 48.0 X 3.2 96 48 3.2 6.71
96.0 X 48.0 X 4.0 96 48 4.0 8.22
96.0 X 48.0 X 4.8 96 48 4.8 9.66
100.0 X 50.0 X 3.2 100 50 3.2 7.01
100.0 X 50.0 X 4.0 100 50 4.0 8.59
122.0 X 61.0 X 3.6 122 61 3.6 9.67
122.0 X 61.0 X 4.5 122 61 4.5 11.88
122.0 X 61.0 X 5.4 122 61 5.4 14.01
145.0 X 82.0 X 4.8 145 82 4.8 15.92
145.0 X 82.0 X 5.4 145 82 5.4 17.74
172.0 X 92.0 X 4.8 172 92 4.8 18.71
172.0 X 92.0 X 5.4 172 92 5.4 20.88
200.0 X 100.0 X 4.0 200 100 4.0 18.01
200.0 X 100.0 X 5.0 200 100 5.0 22.26
200.0 X 100.0 X 6.0 200 100 6.0 26.40
MS Angles

We offer a wide assortment of ms angles to our clients. These MS Angles are widely used in different industry applications. We also provide customization on our range as per the specification of clients. Which are used extensively in fabrication industry. This is manufactured from high-grade mild steel, which is stiff and hard. Used in bracket, trimming, framing and in reinforcements. Our range of mild steel angles are high performing.

These have different Qualitative Features as  Following

  •   Durable
  •   Very sturdy
  •   Easy to install
  •   Rust free
  •   Abrasion fre

Applications Area:

  •   Architectural Applications
  •   Construction Industries
  •   Multi-storied building
  •   Fastening industry
  •   Overhead cranes
  •   Fabrication
  •   Bridges.
  •

Angles specifications

Rationalised sizes of Angles and Section Weight kg/m

3 4 5 6 8 10 12 16 18 20Size 25
20*20 0.9 1.1
25*25 1.1 1.4 1.8 2.2
30*30 1.4 1.8 2.2 2.8
35*35 1.6 2.1 2.6 3.0
40*40 1.8 2.4 3.0 3.4
45*45 2.1 2.7 3.4 4.0
50*50 2.3 3.0 3.8 4.5
55*55 4.1 4.9 6.4 7.0
60*60 4.5 5.4 7.0 8.6
65*65 4.9 5.8 7.7 9.4
75*75 5.7 6.8 8.9 11.0
80*80 7.3 9.6 11.8 14.0
90*90 8.2 10.8 13.4 15.8
100*100 9.2 12.1 14.9 17.7
110*110 13.4 16.5 19.6 24.2
130*130 15.9 19.7 23.4 28.9
150*150 22.8 27.2 35.8 39.9 44.1
200*200 36.6 48.5 54.0 60.0 73.6
MS Channels

We are amongst the leading suppliers of MS channels, which are made of high grade steel that adds anti-corrosion properties and high tensile strength to the finished range. These are available in dimensions of 75mm x 45 mm to 250 mm. We can also provide these in customized width, height and material thickness.







Channels Specifications
Rationalised sizes of channels

Dimensions mm Sectional Weight kg/m Length m
41 x 32 4.79 10 to 12
or all dimensions
75 x 40 7.10
100 x 50 9.60
125 x 65 13.70
150 x 75 16.80
175 x 75 19.60
200 x 75 22.30
200 x 76 24.20
225 x 80 26.01
250 x 80 30.50
250 x 82 34.20
300 x 90 36.30
400 x 100 50.10
10" x 3" 28.69
10" x 3.5" 36.40
MS Beams
in mm Per Feet Per Mtr.
100 x 50 2.432 7.979
125 x 70 4.023 13.199
150 x 75 4.571 14.997
175 x 85 5.943 19.499
200 x 100 7.893 25.897
250 x 125 11.612 38.099
300 x 140 14.782 48.500
350 x 140 16.125 52.906
400 x 140 19.080 62.601
450 x 150 22.280 22.280
500 x 180 26.730 87.700
600 x 210 37.370 122.600

MS Flats

We stand as one of the best suppliers of MS flats in india. Our steel flats have high tensile strength, extra bendability, higher elongation values and are corrosion resistant. Our mild steel flats are on a high note on indian market although, in general, round bars are preferred over them. They have high weldability because of less carbon content. All these qualities have rendered us a supreme position as the best steel flats manufacturer in india and we intend to improvise and innovate with every successive year.







M. S. Flats specifications

Thickness mm Weight Kg/m
Size mm 3 5 6 8 10 12 16 18 20 22 25
16 0.6 0.8 1.0 1.3 1.5 2.0 2.3 2.5 2.8 3.1
20 0.6 0.8 0.9 1.3 1.6 1.9 2.5 2.8 3.1 3.5 3.9
25 0.8 1.0 1.2 1.6 2.0 2.4 3.1 3.5 3.9 4.3 4.9
32 1.1 1.3 1.5 2.0 2.4 3.0 4.0 4.5 5.0 5.5 6.3
35 . . 1.6 . 2.8 . . . . . .
40 1.4 1.6 1.9 2.5 3.1 3.8 5.0 5.7 6.3 6.9 7.8
45 . . 2.1 . 3.5 4.2 . . . . .
50 1.7 2.0 2.4 3.1 3.9 4.7 6.3 7.1 7.8 8.6 9.8
63 . 2.5 3.0 4.0 4.9 5.9 7.9 8.9 9.9 10.9 12.4
65 . . . 4.1 5.1 6.1 . . 10.2 . .
75 . . . 4.7 5.9 7.1 . . 11.8 . 14.7
80 . 3.1 3.8 5.0 6.3 7.5 10.0 11.3 12.6 13.8 15.7
100 . 3.9 4.7 6.3 7.8 9.4 12.6 14.0 15.7 17.5 19.6
125 . 4.9 5.9 7.8 9.8 11.8 15.7 17.7 19.6 21.6 25.5
150 . . . . . 14.1 . 18.8 23.6 . 29.4
160 . 6.3 7.5 10.0 12.6 15.1 20.1 22.6 25.1 27.6 31.4
180 . . . . . 17.0 22.6 25.4 28.3 . .
200 . 7.8 9.4 12.6 15.7 18.8 25.1 28.3 31.4 34.5 39.2
250 . 9.8 11.3 15.7 19.7 23.6 31.4 35.3 39.2 43.2 49.1
TMT Bars

The Thermo Mechanically Treated TMT steel bars also known as reinforcement steel and wire rods are primarily used by the construction industry. Its high corrosion and rust resistance features make it the first choice for buildings in costal areas and in areas of high humidity. The manufacturing process of TMT involves 3 stages of treatment Quenching, Self tempering and Atmospheric Cooling.

CDW Tubes

We provide a huge gamut of CDW Tubes that is highly acknowledged in the markets. Cold Drawn Welded Tubes are used in applications requiring high dimensional accuracy, better surface finish, superior physical properties and non standard sizes. Chemical composition of our Cold Drawn Welded Tubes can be maintained according to the customer requirement. Highly durable, our Cold Drawn Welded Tubes provide long lasting excellent performance. We have carved a niche as one of the overruling CDW Steel Tubes suppliers based in India.


Applications

  •   Automotive
  •   Boiler & Heat Exchangers
  •   Shock Absorbers
  •   Textiles
  •   Cylinder bore for special applications
  •   Front fork tube for two-wheeler
  •   Air Heater
  •   GEN. EGG. & Propeller Shafts


Dimensions

  •   Outer Diameter (MM) : 4.00MM TO 114.00MM
  •   Thickness (MM) : 0.9 MM to 50 MM
  •   Length : Upto 9 Mtrs.
Seamless Pipes

Seamless pipe as the name suggests is a pipe without a seam or a weld-joint in contrast to Seam or Welded pipe. In a Seam or Welded pipe, the seam or the weld-joint is the weaker part of the pipe limiting the strength of the pipe to the strength of the weld-joint. Whereas the seamless pipe does not have any such joint and thus has uniform structure & strength all over the pipe body. Thus the seamless pipe can withstand higher pressure, higher temperature, higher mechanical stress & corrosive atmosphere and find wide applications in Oil & Gas, Refinery, Petrochemical, Chemical, Fertilizer, Power, Automotive, Bearing, Mechanical & Structural applications.

Spiral Welded Tubes

tyutu

Spiral Welded Tubes

ERW (Electrical Resistance Welding) pipes are manufactured by cold forming of steel coil into a round cylindrical shape. In the initial times it was done with the low frequency A.C. current to heat the edges. Now, since 1970 the low frequency process changed to high frequency A.C. current to produce a higher quality weld. ERW steel pipes and tubes are used in various engineering purposes, fencing, scaffolding, line pipes etc. ERW steel pipes and tube are available in various qualities, wall thicknesses, finished and diameter.

Boiler Tubes

Boiler has played an important role in the modern world from the early days of industrial revolution. Now-a-days boilers are widely used by Utility, Industrial, Commercial & Institutional sectors for heating and power generation. With the ever increasing demand for power, the requirements of utility boilers have gone up manifold in recent years. Tubes & pipes form the major part of any boiler in various applications like economizer, super-heater & headers. Size, grade, quantity of tubes & pipes depend on the design of the boiler which is based on fuel, temperature, pressure & volume of steam-flow. There is also continuous efforts to increase the efficiency of the boiler. With the demand for high capacity & high efficiency boilers, the demand for higher grade tubes & pipes have increased substantially.

Scaffolding Pipes

Scaffolding Pipes/Tubes

For supporting man and materials, tools and tackles during construction, alteration, demolition and maintenance works.







Technical Specifications

Scaffolding Pipes are widely used for supporting man and materials, tools and tackles during construction, alteration, demolition and maintenance works because of their several advantages over conventional type of timber / bamboo scaffolding.

Application Areas

Our range of fencing pipes and tubes are available in a variety of dimensions and can also be customized as per the client's requirement. Fencing tubes have a wide range of applications in:

» Handrails
» Columns
» Posts
» Piling
» Sand-wash
» Casing

» Culverts
» Fence
» Caissons
» Sign poles
» Bumpers
» Bracing

» Parking meter posts
» Towers
» Supports
» Rollers

OD
» 48.3 mm
» 38 mm
» 60 mm

WI
» 2.9/9
» 2.9/9
» 2.9/9

MS Plates

Engaged in manufacturing and exporting of MS plates, stainless steel coils, stainless steel plugs, stainless steel seamless, stainless steel sheets, stainless steel shims, steel sheets, steel squares, steel strips.

Specification
LIST OF PRODUCTS WITH EQUIVALENT STANDARDS
Products Indian Standard American Standard British Standard Japanese German
IS ASTM/ANSI BS/EN JIS DIN
H.R.Pipes
Black Pipes-Structural IS 1161/1998 ASTM A500
GR A/1993
BS 4360
BS 1775/64
JIS G3444/1994 DIN 2439 - 2441
Black Pipes - Others IS 3589/1991 ASTM A53/1993 BS 1387/1985/ ---- ----
IS1239
(Part 1)/2004
---- EN 10265 : 2004 ---- ----
Galvanized Pipes IS 1239
(Part 1)/2004
ASTM A53/1993 BS 1387/1985/ ---- ----
Idlers Tubes IS 9295/1983 ---- EN 10256 : 2004 ---- ----
General Engineering ---- ---- EN 10296 : 2003 ---- ----
Tubes IS 3601/1984 ---- BS 1775 BS 6323/1982 JIS G3445/1983 DIN 2393/1994
Hollow Section Tubes
(RHS/SHS)
IS 4923/1997 ASTM A500 GR A/1993 BS 6323/EN10305-5:2003 JIS G3466/1982 ----
Air Heater Tubes IS 3601/1984 ASTM A214/1990 BS 3059
(PART 1) :1987
JIS G3461/1984 DIN 17177/1979
Water Wells IS 4270/2001 ---- ---- ---- ----
C.R.Tubes
Furniture Tubes IS 7138/1973 ---- ---- JIS G3445/1983 ----
Bicycle Tubes IS 2039/1991 ---- BS 1717 :1983 ---- ----
Automotive Tubes IS 3074/1979
IS 5429/1979
ASTM A 513/1994 BS 980 BS 6323 :1982
EN10305
JIS G3445/1983 DIN 2393/1994
DIN 2394/1994
Transformer Tubes IS 8036/1976 ---- ---- ---- ----
General Engineering Tubes IS 3601/1984 ---- BS 1775 BS 6323 :1982 JIS G3445/1983 DIN 2393/1994
DIN 2394/1994
Hollow Section Tubes(RHS / SHS) IS 4923/1997 ASTM A500 GR A/1993 BS 6363 JIS G3446/1982 ----
Electrical Conduit IS 9537 (Part -1)/1980 ANSI C 80 1 BS 4568 ---- ----
Pregalva Pipes
(Galva Bond)
IS 3601/1984 ---- ---- ---- ----
C.R.C.A.Strips
Cold Rolled Steel
Sheets & Strips
IS 513/1994 ASTM A622, A621, A569 BS 1449 JIS G3131 DIN 1614 Part1
Scaffolding ---- ---- BS 1139 (Part 1)/1982 ---- ----
Swaged Poles(Electrical) IS 2713/1980 ---- ---- ---- ----
+
Live Chat

We Are here to help You, CALL US : 7810004320 / 30817525

Send Enquiry

Tell Us Your Requirement
We will get Back to you Shortly.
